Trina 415W Solar Panel BLK/BLK

Name: Trina 415W Solar Panel BLK/BLK
Brand: Trina
SKU: TSM-415NE09RC.05
Price: 132.8 USD
Availability: InStock

by Trina

SKU TSM-415NE09RC.05

Availability:

In stock

$132.80 - $132.80

$132.80

$132.80 - $132.80

$132.80

The Trina Solar TSM-415NE09RC.05 is a high-efficiency monocrystalline module crafted for performance, durability, and elegant aesthetics. Part of the Vertex S series, this panel incorporates advanced solar technologies, including PERC and half-cut cell architecture to boost overall energy yield and reduce resistive losses. Its bifacial design enables both sides of the panel to absorb sunlight, improving efficiency by up to 30%—ideal for space-conscious systems seeking maximum output.

Designed with sleek, all-black styling, the panel blends effortlessly into any rooftop. Its durable construction—featuring an anodized aluminum frame and tempered glass—ensures long-term reliability even in harsh climates.

Recommended for: residential rooftops, commercial systems, grid-tied and off-grid installations, and building-integrated solar applications.

Minimum Purchase: 10 Units
Wattage: 415W | Bifacial Monofacial Module
Efficiency: Maximum 20.8%
Dimensions: 69.37 x 44.65 x 1.18 inches
Weight: 47 lbs
Connector: MC4 EVO2
Warranty: 25 Years Product and 25 Years Performance Warranty

Quantity

Key Features

High Efficiency: With 415W of power output and 20.8% efficiency, this panel delivers exceptional performance, even in low-light conditions. Bifacial design increases energy harvest by up to 30%.

Advanced Technology: Built with 108 half-cut monocrystalline PERC cells, it offers reduced resistance, improved shade tolerance, and enhanced overall output.

Reliable in Extreme Weather: Engineered to withstand up to 6000 Pa front and 4000 Pa rear loads, this panel is ready for snow, wind, and harsh environmental conditions.

Sleek All-Black Aesthetics: Designed for modern rooftops, the all-black frame, backsheet, and uniform cell color provide a smooth, premium appearance.

Long-Term Durability: Backed by a 25-year product and 25-year performance warranty, with only 0.25% annual degradation after the first year, ensuring 89.4% output after 25 years.

Smart Investment: Thanks to high efficiency and low degradation, this panel pays off faster and produces more power over its lifetime.

Technical Specifications

Power Output (Pmax): 415W
Open Circuit Voltage (Voc): 50.5V
Module Efficiency: 20.8%
Dimensions: 69.37 x 44.65 x 1.18 inches
Weight: 47 lbs
Cell Type: Monocrystalline (144 half-cut PERC cells)
Frame Material: Anodized Aluminum Alloy
Frame Color: Black
Connector Type: MC4-Evo2
Max System Voltage: 1500V DC
Operating Temperature Range: −40°F to +185°F
Applications: Residential, Commercial, Grid-Tie, Off-Grid, RV, Boats
Pallet Quantity: 36 panels per pallet
Model Number: TSM-415NE09RC.05
Warranty: 25 Years Product and 25 Years Performance Warranty

Product Sheet

Trina 415 Solar Panel
